This benchtop colloid mill is suitable for making sesame paste, sunflower seed butter, cashew nut butter, pecan butter, etc. Its biggest advantage is high output, and can be directly to the whole peanut grinding paste.
Structural Features Of Benchtop Colloid Mill:
The machine is divided into vertical and horizontal specifications, the main engine is composed of shell, stator, rotor, regulating mechanism, cooling mechanism and motor. Its main parts are made of stainless steel, corrosion - resistant, non - toxic. Users can choose different specifications of benchtop colloid mill according to the characteristics of different materials, production efficiency and usage, so as to achieve good results.
Colloid Mill Machine Video:
Benchtop Colloid Mill Characteristics:
1. Compact structure, novel appearance, overall health, environmental protection and energy - saving, high efficiency.
2. With vertical motor, body and motor in parallel, belt drive.
3. Novel design, simple operation, convenient installation and maintenance, small size, high efficiency.
4. The contact material part of benchtop colloid mill is made of stainless steel, good corrosion resistance, no pollution to medicine, food and chemical raw materials, the grinding teeth are made of high hardness and corrosion resistant alloy, which can crush hard materials.
5. The separation of the motor and the grinding seat is characterized by good stability, easy operation and long service life, material leakage will not cause the phenomenon of burning motor, no wear and tear, corrosion resistance and less failure. Through belt pulley transmission, change transmission ratio and improve rotating speed, the material can be crushed more finely.
6. Vertical benchtop colloid mill is directly driven by the special lengthened shaft motor, with compact structure, light weight and small floor space.
Working Principle Of Colloid Mill for Sale
The core structure and working principle of colloidal grinding are step by step grinding method of stator and rotor with intermeshing internal teeth, their motion combination enables the medium to pass through hundreds of thousands of times of shear and grinding in colloid mill. In the process from the entry to the exit of the colloid mill, the grinding area of each step varies with radial depth, the motion direction and instantaneous velocity of the medium are constantly changed, intense intermolecular friction, extrusion and rubbing caused the chain of medium molecules to break while being sheared by the cutter tooth. And reconstitute the molecular chain to achieve high standards of grinding.
There are different specifications of colloid mill for sale in our company, welcome to contact us for more details.
Technical Data
(kg/h)
(mesh)
(mm)
(KG)
